function to verify probe internal devices and/or functions. More powerful and potentially dangerous
diagnostic functions are available under the “ADMINISTRATOR” and “SERVICE” access rights.
6.1.2.1 The Diagnostics Menu
The Diagnostics Menu is presented by selecting: <2> [DIAG] from the "Service menu”.
OCEAN SEVEN 310 - ID:0317003 {USR}(1.0_10 05/17)Jun 13 14:33:07.88 2017
<0>[DIUP]-Leave Diagnostics menu
<1>[DITT]-Test 16bitADC
<2>[DISR]-Service reading
<3>[DISI]-Serial interface
<4>[DIRT]-Real time clock/calendar
<5>[DITB]-Time base
cmd>
Selection of the desired function is performed by typing one of the acronyms in square brackets or the
numeric key between the <> brackets. By pressing the <ESC> key or <DIUP> command, the programme
returns to the "Service Menu", while pressing the <ENTER> key re-displays the "Diagnostics menu”.
6.1.2.2 Test 16bit A/D Converter
This command allows the operator to watch the probe analogue inputs. Once invoked, this command
shows the following acquisitions in real time on the PC screen until a character is typed on the PC
keyboard. Acquired data is shown in ADC Counts or in mV.
16bitADConverter test
Show data in mV ?:No type [Y]es or [N]o < n
CH-#0 CH-#1 CH-#2 CH-#3 CH-#4 CH-#5 CH-#6 CH-#7
0.0 0.0 0.0 0.0 8930.0 0.0 0.0 0.0
0.0 0.0 0.0 0.0 15632.0 0.0 0.0 0.0
0.0 0.0 0.0 0.0 20659.0 0.0 0.0 0.0
0.0 0.0 0.0 0.0 24427.0 0.0 0.0 0.0
0.0 0.0 0.0 0.0 27253.0 0.0 0.0 0.0
0.0 0.0 0.0 0.0 29373.0 0.0 0.0 0.0
0.0 0.0 0.0 0.0 30963.0 0.0 0.0 0.0
0.0 0.0 0.0 0.0 32155.0 0.0 0.0 0.0
0.0 0.0 0.0 0.0 33049.0 0.0 0.0 0.0
0.0 1.0 0.0 0.0 35717.0 0.0 0.0 0.0
6.1.2.3 Service reading
This command shows in real time the acquisition concerning the probe internal temperature, and
analogue reference voltage. The following message appears on the PC screen:
System working voltages
External Pwr [3.72]V
Battery [3.34]V
uP int Temp [15.96]C
uP VDC [3.27]V
uP Vref [3436.55]mV
Type <any key>To continue
