30
Advanced Setup Table
FD = Factory Default Setting
TO ENTER MENUS .......BUTTON PRESS
Setup Steps ..................... MODE & OVERRIDE for 5 sec.
Time Schedule ................ MODE & UP for 2 seconds
Emergency Heat ............UP & OVERRIDE for 2 seconds
TO ENTER MENUS ......BUTTON PRESS
Lockout Buttons ............MODE, UP & DOWN for 2 sec.
Calibration.......................MODE & DOWN for 2 sec.,
............................................ then MODE
Wireless Setup .............. OVERRIDE for 5 Seconds
Step # Description Pg # Range FD
1 CLOCK 14 12A - 12A 12P
2 WEEKDAY 14 Monday - Sunday Monday
3 SHOW CLOCK 14 On, Off On
4 PROG 15 On, Off On
5 BACKLIGHT 15 On, Off Off
6 NIGHTLT 15 On, Off Off
7 NIGHTLT START 15 12A - 12A 8:00P
8 NIGHTLT STOP 15 12A - 12A 6:00A
9 NUMBER OF WATER PIPES 16 4 PIPE, 2 PIPE 4 PIPE
10 2 PIPE SUBMODE
(only if prior step=2)
16 Heat only, Cool Only
Auto Change, Total Elec
Auto Change, Aux Heat
Auto Change
Auto Change
11 1ST STAGE DEADBAND 17 1 - 6 degrees 2
12 MINIMUM HEAT/COOL SPREAD
(unless 2 pipe single mode)
17 0 - 6 degrees 2
13 SETPOINT LIMITS 18 On, Off Off
14 MAX HEAT SETPOINT 18 35 - 99 degrees 82
15 MIN COOL SETPOINT 18 35 - 99 degrees 66
16 MAX OVRRIDE TIME IN HOURS 19 0 - 4 hrs 4
17 DISPLAY F/C 19 F, C F
18 CONTINUOUS FAN, ON (low) or OFF (auto) 19 On, Off Off
19 FAN TYPE, ON (IEC) or OFF 19 On, Off Off
20 WIRED SENSOR TYPE 19 control, monitor control
21 CONTROL TO TEMP SOURCE 20 thermostat, sensor thermostat
22 PRE-OCC FAN PURGE TIME 20 off - 3 hrs off
23 HOT WATER VALVE TYPE 21 n.o / n.c. n.c.
24 CHILLED WATER VALVE TYPE 21 n.o / n.c. n.c.
25 DRY CONTACT POLARITY 22 n.o / n.c. n.c.
26 DRY CONTACT USE 22 occupied, condensate, fdd,
holiday
condensate
27 SKYPORT 23 On, Off On
28 API 23 On, Off Off
29 TIME API 23 On, Off Off
To Next Page
