GB
2 - TECHNICAL INFORMATION KID 70
2 - Pag. 12 / 16
2.5 TECHNICAL DATA AND PERIMETRAL AREAS
Technical data table
KID 70
Round bar diameter
Ø min5 mm
(3/16")
Ø max 70 mm
(2"3/4)
Square bar side
min 5 mm
(3/16")
max 50 mm
(2")
Hexagonal bar height
min 5 mm
(3/16")
max 60 mm
(2 1/4")
Maximum bar length
500 mm
Maximum bar length
1615 mm
Magazine capacity (Kg.)
250 kg.
(N. 60 barres Ø 10 mm)
Bar change time
(with 1000 mm bar)
50 sec
Feed speed
0-500 mm/sec
Return speed
1000 mm/sec
Supply voltage
230/400 Volt
Control voltage
24 Volt
Installed power
2 kW
Weight
580 kg.
Note: the maximum length is valid for a lathe that can contain it. This means that the bar
length should never exceed that of the cylinder head and of the lathe spindle.
