Loading axis height table
Screw positionX - Loading axis
height
Threaded holes on the
base
Slots on the supports
900÷937 B 1 - 3
938÷969 A
970÷1007 B
2 - 4
1008÷1039 A
1040÷1077 B
3 - 5
1078÷1109 A
1110÷1147 B
4 - 6
1148÷1179 A
1180÷1217 B
5 - 7
