IEMCA KID 70 - Page 25

GB
2 - TECHNICAL INFORMATION KID 70
2 - Pag. 14 / 16
Bar and bar pusher diameters table
ø A - Bar diameter
(mm)
Ø B - Bar pusher
diameter (mm)
ø C - Bar pusher
bearing diameter
(mm)
ø D – Spindle liner
(mm)
5÷12 10 12 14
10÷19 12 15 16
16÷60 18 21 22
24÷80 24 26 28
