6 - USE AND OPERATION KID 70
GB
6 - Pag. 9 / 14
6.10 STARTING THE AUTOMATIC CYCLE
If the bar feeder conditions allow no automatic cycle start, please follow these instructions:
• Turn lathe power supply on.
• Turn the bar feeder main switch
to I (ON) to switch the bar feeder power supply on.
• Press the bar feeder start button
to start up the bar feeder and hold it down until it
lights up.
• Press this button
to select "manual operation mode".
• Let bar feeder devices reach the cycle start position, when necessary.
• Press rapidly this button twice
to set "bar feeder zero".
• Turn selector switch
and hold it to the left: the selecting device, the bar drop control
device and the bar pusher are lifted.
• Turn selector switch
and hold it to the left: the alarm on the display is removed while
the bar pusher and the guide channel are lowered.
• Select the desired workpiece feeding mode (parameter 29).
• Press this button
to start the automatic cycle.
