GB
6 - USE AND OPERATION KID 70
6 - Pag. 14 / 14
Partial cycle
This operation can be carried out to remove a bar from the lathe.
• Turn selector switch and hold it to the left; the bar pusher will reach its back position.
• Turn selector switch and hold it to the left; the bar pusher and the guide channel are
lifted but no bar is loaded.
• Remove the bar from the guide channel of the bar feeder.
• Turn selector switch
and hold it to the left again; the error on the display will be
removed while the bar feeder start condition is set up again.
