23
ENGLISH
Damping for the switching outputs
Pressure peaks of short duration or high frequency can be
filtered out.
dAP-value = response time between pressure change and
change of the switching status in ms.
• The value for dAP defines the switching frequency (f) of the
output:
dAP
f [Hz]
3
170
6
80
10
50
17
30
30
16
60
8
125
4
250
2
500
1
Setting of the display
7 options can be selected:
d1 = update of the measured value every 50ms.
d2 = update of the measured value every 200ms.
d3 = update of the measured value every 600ms.
The update interval only refers to the display. It has no effect on
the outputs.
rd1, rd2, rd3 = display as d1, d2, d3; but rotated 180°.
OFF = In the Run mode the display of the measured value is
deactivated. If one of the buttons is pressed, the current
measured value is displayed for 15s. Another press of the
Mode/Enter button opens the Display mode.
The LEDs remain active even if the display is deactivated.
Delay time for the switching output
dS1 = switch-on delay; dr1 = switch-off delay.
The output does not immediately change its switching status
when the switching condition is met but when the delay time
has elapsed. If the switching condition is no longer met when
the delay time has elapsed, the switching state of the output
does not change.
• Setting range: 0 (= delay time not active) - 0.2 ... 50s,
• in steps of 0.2s.
