8.1.5 Fieldbus: configure Modbus port
12284
The configuration of the IP settings of the fieldbus port is only possible via LR DEVICE.
To configure the fieldbus port:
► Select [Fieldbus] menu.
> The menu page shows the current settings.
► Set the following parameters as required:
Name
Description
Possible values
[DHCP]
Activate/deactivate the DHCP client of the
device
[Static IP]
IP parameters are set by the
user
[DHCP]
IP parameters are set by a
DHCP server in the network.
[BOOTP]
IP parameters are set via the
Bootstrap Protocol (BOOTP)
[IP address]*
IP address of the Modbus port
Factory setting: 192.168.1.250
[Subnet mask]*
Subnet mask of the IP network
Factory setting: 255.255.255.0
[Default gateway IP address]*
IP address of the gateway
Factory setting: 0.0.0.0
[MAC address]
MAC address of the Modbus interface
The value is firmly set.
[Fieldbus firmware]
Firmware version of the Modbus stack
e.g. 2.6.0.5
[Process data length]
Length of the process input data and process
output data per IO-Link port
2 bytes input
2 bytes output
2 bytes input data, 2 bytes
output data
4 bytes input
4 bytes output
4 bytes input data, 4 bytes
output data
8 bytes input
8 bytes output
8 bytes input data, 8 bytes
output data
16 bytes input
16 bytes output
16 bytes input data,
16 bytes output data
32 bytes input
32 bytes output
32 bytes input data,
32 bytes output data
[Swap]
Sequence of bytes in the data word
off
as Array of Bytes
on
as integer16 value; when
process data is updated,
bytes will be exchanged
* ... can only be edited if parameter [DHCP] = [Static IP]
► Save changed values on the device.
