ifm Device Manual IO-Link Master with Modbus interface CabinetLine 8 Ports IP 20 (AL1940) 05 / 2018
Appendix Technical data
>
13.1.4 Inputs
22820
Inputs
Number of digital inputs
16; (IO-Link Port Class A: 8 x 2)
Switching level high [V]
11...30 DC
Switching level low [V]
0...5 DC
Digital inputs protected against short circuits
yes
>
13.1.5 Outputs
22821
Outputs (digital)
Output function
8; (IO-Link Port Class A: 8 x 1)
Max. current load per output [mA]
200
Short-circuit protection
yes
>
13.1.6 Interfaces
10921
Interfaces
Communication interface
Ethernet; IO-Link
Communication interface
IO-Link; TCP/IP; Modbus TCP
Ethernet
Transmission standard
10Base-T; 100Base-TX
Transmission rate [MBit/s]
10; 100
Protocol
TCP/IP; Modbus TCP
Factory settings
 IP address: 192.168.1.250
 Subnet mask: 255.255.255.0
 Gateway IP address: 0.0.0.0
 MAC address: see type label
IO-Link master
Type of transmission
COM 1 / COM 2 / COM 3
IO-Link revision
V1.1
Number of ports Class A
8
IoT interface
Transmission standard
10Base-T; 100Base-TX
Transmission rate [Mbits/s]
10; 100
Protocol
DCP, DCHP, Auto IP
Factory settings
 IP address: 169.254.X.X
 Subnet mask: 255.255.0.0
 Gateway IP address: 0.0.0.0
 MAC address: see type label
