ifm Device Manual IO-Link Master with Modbus interface CabinetLine 8 Ports IP 20 (AL1940) 05 / 2018
Appendix Modbus
>
Command 0x10 – Set mode
23461
The command changes the operating mode of an IO-Link port of the AL1940.
Corresponding parameter: [Port Mode] (→ Mapping: port configuration (→ p. 74))
>
Command request
12221
Register
Contents
Bits 8-15
Bits 0-7
500
Port No.
501
reserved
502
reserved
503
0x10
User ID
504
reserved
505
Target Mode
506 ... 521
reserved
Legend:
 [Port No.]
Number of the IO-Link port
1 word
0x0001
Port X01
0x0002
Port X02
...
...
0x0008
Port X08
 [User ID]
ID to identify the command
1 byte
0x00 .. 0xFF
 [Target Mode]
Operating type of the IO-Link port
1 word
0x0000
deactivated
0x0001
digital input (DI)
0x0002
digital output (DO)
0x0003
IO-Link
