ifm Device Manual IO-Link Master with Modbus interface CabinetLine 8 Ports IP 20 (AL1940) 05 / 2018
Appendix Modbus
>
Command 0x50 – Factory Reset
7254
The command resets all parameters to the factory settings (→ Factory settings (→ p. 64)).
>
Command request
11060
Register
Contents
Bits 8-15
Bits 0-7
500
reserved
501
reserved
502
reserved
503
0x50
User ID
504
reserved
505
0x0055
506 ... 520
reserved
Legend:
 [User ID]
ID to identify the command
1 byte
0x00 .. 0xFF
>
Command response
21514
Register
Contents
Bits 8-15
Bits 0-7
0
reserved
1
reserved
2
reserved
3
0x50
User ID
4
Result
5
Data Length (Number of Bytes)
6
reserved / Error Code
0x55 / Error
7 ... 21
reserved
Legend:
 [User ID]
reflected User ID from request channel
1 byte
0x00 .. 0xFF
 [Result]
Status of the command processing
1 word
0x0000
OK
0x00FF
Error
 [Data Length
(Number of
Bytes)]
Number of bytes that contain relevant user data
1 word
0x0001
1 byte
0x0002
2 bytes
 [Error]
Error ID
1 byte
→ Error codes (→ p. 87)
 [Error Code]
additional error codes
1 byte
depends on the IO-Link device
