ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu System
>
Clone device configuration
7087
The AC142n makes it possible to create an image of the current device configuration, to transfer it to
another device and activate there (clone). The export/import of the configuration file is made via an SD
card.
A device configuration consists of the following settings:
System settings
AS-i 1/AS-i 2 settings
EtherNet/IP settings
PLC applications (incl. PLC task configuration and variables)
The user can only access this function via the local user interface of the device!
Cloning a device configuration is only possible if the following conditions are met.
Source and target device have the same firmware version
Source and target device have the same article number.
>
Save the device configuration
16199
Pay attention to the notes (→ Clone device configuration (→ page 84))!
To save the currently valid device configuration on an SD card:
1 Select the menu page
► >
> Select [Configuration] tab.
2 Save the device configuration
► Insert an SD card with sufficient free space in the SD card slot.
► Press [Export Configuration].
> The device stores the currently valid device configuration on the SD card.
