8.4 Explanation of the menu level 2
Uni Standard unit of measurement for system pressure�
SELd
Display mode:
•Pressure in the unit set in [Uni]�
•Pressure in % of the set scaling of the analogue output�
ASP Analogue start point for system pressure: measured value at which 4 mA is
provided (20 mA if [OU2] = [InEG])�
AEP Analogue end point for system pressure: measured value at which 20 mA is
provided (4 mA if [OU2] = [InEG])�
HI Maximum value memory for system pressure�
LO Minimum value memory for system pressure�
COF Zero-point calibration�
dS1* Switch-on delay for OUT1�
dr1* Switch-off delay for OUT1�
dS2* Switch-on delay for OUT2; only active if [OU2] = [Hnc], [Hno], [Fnc] or [Fno]�
dr2* Switch-off delay for OUT2; only active if [OU2] = [Hnc], [Hno], [Fnc] or [Fno]�
FOU1* Behaviour of output 1 in case of an internal fault�
FOU2 Behaviour of output 2 in case of an internal fault�
P-n* Switching logic for the outputs: pnp or npn�
dAP Damping for switching outputs and display�
dAA Damping for analogue output (OUT2); also has effect on the IO-Link process
value�
diS Update rate and orientation of the display�
CAL Calibration function (setting the curve of measured values)�
CP1 Calibration point 1
CP2 Calibration point 2
SIM Change to menu level 3 (simulation)
rES Restore factory settings�
* menu items not active in 2-wire operation
