IFR FM/AM-1200A

In addition to the two new formats, all encode/decode signalling for-
mats have up to eight (8) digits available on the VFD screen for pro-
gramming (although default programming will still only show five (5)
digits.)
5-10-10 PROGRAMMING EIGHT DIGIT SIGNALING FORMAT OPERATION (INCLUDES
CCJR,
EEA, EIA, ZVEI1, ZVEI2, ZVEI3, NATEL, EURO CCIRH AND
CCIRH4)
Program the formats in eight digits by the following steps:
STEP PROCEDURE
1.
2.
3.
Press: lill~ll+,l
The following will appear on the VFD:
lllclclrlr<l I lelzlzlzlzl I I I I Ill
press: I~ II~ II~ II~ II+ II+ II~ II~ I
The VFD will show:
Press:
to execute the tone format.
5-10-11 ENHANCED 5/6 TONE FORMAT
The enhanced 5/6 Tone signaling format will accept a preamble digit
plus up-to eight trailing digits for signalling sequence; e.g.:
