IFR FM/AM-1200A

Table No.
Tit l e
Page
4- 9 FM/AM-1200S/A Front Panel Controls Applicable
to Oscilloscope Operation ................................... 4-44
4-10
FM/AM-1200S/A Front Panel Controls Applicable
to Spectrum Analyzer Operation ............................. 4-47
4- 11
Horizontal Sweep Selector Control (Analyzer
dispersion Control) Settings ............................... 4-48
4-12
Aliowable Command Formats ................................... 4-52
4-13
RS-232 Remote Commands ...................................... 4-53
5 - 1 Ft·1/AM-1200S/A Front Panel Controls Applicable
to Digital Voltmeter Operation ............................. 5-4
5-2
FM/AM-1200S/A Front Panel Controls Applicable
to DTMF Decoder Operation ....... · ............................ 5-6
5-3 Toneset Frequency Table ..................................... 5-9
5-4
FM/AM-1200S/A Front Panel Controls Applicable
Tracking Generator Operation ............................... 5-16
5-5 Horizontal Sweep Selector Control (Analyzer Dispersion
Control) Settings and Horizontal Sweep Speed ............ 5-18
5-6
Tracking Generator RS-232 Commands ........................ 5-20
~ 5-7 IEEE 488-1978 BUS Messages ................................. 5-23
5-8 GPIB Message Definitions .................................... 5-24
5-9 GPIB Command Format .......................................... 5-28
5-10 GPIB Commands ................................................. 5-29
5 - 11
FM/AM-1200S Front Panel Controls Applicable
to Trunking Test Operations ................................ 5-48
5-12 FM/AM-1200S Front Panel Controls Applicable
to Cellular Testing Operations ............................. 5-61
5-13
RS-232 Remote Cellular Testing Commands .................. 5-100
B-1
Table of I/0 Ports ........................................... B-1
B-2
MIC/ACC Connector Pin Assignments ......................... B-2
B-3
RS-232 Connector Pin Assignments (Standard) ............. B-3
B-4 RS-232 Connector Pin Assignments with Cellular
Testing (Option 15) Installed .............................. B-3
B- 5
GPIB
Connector Pin Assignments ............................. B-4
F- 1
Trunking Channel Low Frequency Band ....................... F-1
F - 2
Trunking Channel High Frequency Band ..................... F-9
