IFYIL GT-25 - 2 Technical Specifications

9
2. TECHNICAL SPECIFICATIONS
• This devices should be installed in accordance with the related regulation
and EU standards.
• Pellet boilers has been produced in accordance with TS EN 303-5 standards.
Technical Specifications
Measured Values
Device type: BOILER
GT–25
GT–15
Class
5
5
Nominal Heat Power
kW
25
15
Minimum Heat Power
kW
8,3
5
Hourly Fuel Consumption (min. - max.)
kg/h
1,9-5,8
1,2 -3,5
Efficiency
%
91,5
91,5
Recommended Flue Pipe Draft
Pa
12
12
Flue Gas Temperature
⁰C
118
112
Design Pressure
bar
3
3
Maximum Operating Water Pressure in Bar
Where Applicable
bar
3
3
Test Pressure
bar
4,5
4,5
Type of Pellet Fuel
mm
ϕ6/L:30
Electric Power Supply
V
ac
/Hz.
230V
ac
/50Hz
Electric Consumption
W
200
200
Weight
kg
273
230
Boiler Water Volume
Lt.
50
41
Fuel Tank Capacity
kg
50
40
Dimensions (width X depth X height)
mm
604 x 901 x 1387
604 x 793 x 1257
Connections
Delivery / Return Pipes
in
1
Combustion air intake
mm
Ø 60
Chimney connection diameter
mm
Ø 100
