3. Names of Parts
3.1 Names of Parts and Their Functions
Front
Back
Note: Various signal inputs (Video, S-Video and RGB) are
automatically terminated. With the main power off,
however, the S-Video signal terminates itself off even
when the output connector is not connected.
1 2 3 4 5 6 7 8
9
10
11
12
13
14
15
16
22 21 20 19 18 17
㽲
Power indicator
㽳
Standby power switch
㽴
Input 1
㽵
Input 2
㽶
MENU
㽷
PIP SEL /-
㽸
SWAP/+
㽹
Contrast/
Brightness/
Exit
㽺
SDI input
㽻
SDI output
㽼
Video input/output
㽽
S-Video input/output
㽾
Y/G input/output
㽿
Pb/B input/output
㾀
Pr/R input/output
㾁
Sync input/output
㾂
PC (RGB) 1 input
㾃
DVI-D1 input
㾄
Option input
(SDI or PC/DVI)
㾅
COM (Service Port)
䋲䋱
AC input
䋲䋲
Power switch
䋲䋳
Potential
Equalization
Terminal
This symbol
appears next to the
display’s Potential
Equalization
Terminal (ground
post)
