TRADUCTION OF THE ORIGINAL INSTRUCTIONS FOR USE
BS 400/60 AFI-Eing ED.2011 rev.00 30/60
20 - DRAINING OF USED / PRODUCED SUBSTANCES
Please remember to follow the current Law Norms concerning the draining of:
- materials used by the machine (for example hydraulic circuit oil, reduction gear oil, oil for installations of
lubrication and so on);
- working scrap materials or materials not usable anymore (for example ferrous and not ferrous chips, tools like:
saw bands and blades and so on);
- substances used for cleaning and maintenance;
- materials used in some periods of machine life only (for example for packing, transit and so on).
Do not throw the packing away as it might be used in case you should ship the machine or return it to the distributor
or to the service staff - when the machine is still under guarantee.
21 – TROUBLE-SHOOTING
The solution of most inconveniencies that could happen during the working can be found by consulting this
paragraph.
The first part concerns the machine working and includes a list of the possible defects with respective controls that
must be made; the second part concerns the inconveniences that can be found by checking the blade and / or the
cut pieces.
If your problem is not included in the mentioned ones or you need the presence of qualified technicians, please get
in touch with the manufacturer or the reseller by keeping in evidence this instruction book .
12.1 - DEFECTS CAUSED BY THE MACHINE
Problem Check
A* The band electric motor does not work 3-4-5-9
B* The hydraulic circuit motor does not work 1-2-3-4-5-9-17
C* The electronical/electric panel does not light on 6-7-8-9
D* No enough pressure in the hydraulic circuit 10-11-12-13
E* The pump of the hydraulic unit is noisy 14-15-16-17
F* The coolant is not sufficient 18-19-20-21
G* The workpiece moves or deformes 22-23-24
H* The cycle don’t start 23
LIST OF THE PARTS THAT MUST BE CHECKED
1 = Plug is right inserted in the socket
2 = Main switch
3 = The motor is burnt or demaged
4 = Electric supply is not right
5 = Transmission blocked between blade and blade
arbor
6 = Fuses on the primary of the transformer
7 = Fuses on the secondary of the transformer
8 = Transformer demaged or burnt
9 = Connection of the supply cables
10 = Oil level in the tank of the hydraulic unit
11 = Loss from pipes and/or connections
12 = The adjustments screw of the maximum
pressure valveis loosened
13 = the maximum pressure valveis broken
14 = Quality of the hydraulic oil (consumed, too much
liquid)
15 = There is some water in the oil and / or there is
some condensate in the tank
16 = Too high circuit pressure (over 20 BAR)
17 = The hydraulic pump locked (seizure, expansion,
oxidation)
18 = The circuit taps are closed
19 = The cooling filters are obstructed or must be
cleaned
20 = The electropump does not work (see 3-4-5-9-24)
21 = The tank is empty or dirty
22 = Excesive cutting feed
23 = The vice is not closed enough (or is too closed),
the piece is not rightly clamped
24 = The control LUBRICANT OFF is active (pos. 22 /
dr. RI0055 for models SH-E, SHI-E)
12.2 - PROBLEMS OF THE BLADE / CAUSES /
SOLUTIONS
