TRADUCTION OF THE ORIGINAL INSTRUCTIONS FOR USE
BS 400/60 AFI-Eing ED.2011 rev.00 6/60
6 – TECHNICAL CHARACTERISTICS
- Electronic automatic bandsaw, hydraulically driven; mitre cutting from 0° to 60° left
- Hydraulic fixed vice, anti-burr hydraulic vertical vice on the unloading side
- Adjustment of the blade tension from the front side of the sawframe, checked by an end-stroke
- Blade tension 2000 kg/cm, blade guides with hard metal pads
- CUTTING CYCLE: after setting the cutting length and the number of cuts, a trim cut is performed, then the bar
is cut till the end of the program
- PLC driver with programming of all operations by means of the keyboard; machine status shown on display,
including blade life and speed, piece counter, cycle time, motor absorption; working anomalies shown, too
- Mechanical device (position sensor) that allows the sawframe to lower quickly toward the material and detect
automatically the start-cut point
- Feeder with 400mm opening, maximum stroke 515 mm, minimum stroke 2,5 mm, minimal scrap-end 80
mm, selection of the number of cuts (1-9999) and feeder strokes (1-29) by means of the keyboard
- Manual selection of the cutting length with digital reading and decimal accuracy
- The version with electronic Inverter for variable blade speed has an additional servo-ventilation
- Main switch with minimum tension coil, emergency button, thermic and magnetic motor protection
- Removable chip collector tank, coolant tank with electro-pump, washing gun for cleaning, hydraulic unit with
oil, blade-cleaning brush, bi-metal blade
- Tools and user’s book
- In compliance with CEE Safety and Electro-magnetic Compatibility Norms (EMC)
Electrics according to the Norms EN60204-1, EN55011, EN50082-2
If not differently indicated, all data reported in this manual refer to the standard version, suitable for
working at 400 V / 50 Hz THREEPHASE.
= cutting capacity ( max. dimensions on PROFILES & TUBES)
= BLADE DIMENSIONS = WEIGHT =VICE OPENING
= motor choice and blade speeds (at 50 Hz);
