9-2
1. Confirm the connection
PC dedicated software is used for JUE-500 software updating.
Prepare a PC and connect it to Ethernet port of JUE-500, with LAN cable.
About the connecting procedure, refer to [6.2 Ethernet port PC connection] (p6-8) in this manual.
Power
supply
PC
Handset
ADE
LAN cable
