Table 10.2 Explanation of Alarm Pack
Status Line
Menu Items Contents
Example/Correct value
Remarks
EIRP Displays transmitting output level 0 to 20.1
ATT ADE attenuator value
HPA
Displays detection value of temperature
sensor of HPA section
-125 to +125
About 0 to 30 degrees higher compared with
the outside temperature.
ADJ EIRP ADJ RFS setting value 0 to 255
SAT AZ
SAT EL
Displays Azimuth/Elevation of the
satellite.
AZ/0.0 to 359.9
EL/0.0 to 90.0
Displayed satellite angle is calculated from
ship’s position by ADE, not the angle of
antenna and satellite, actually
BR
Displays bearing angle of the antenna
(Displays the bearing which actually the
antenna points, when we assumed the
prow direction is starboard 90 degrees
to clockwise 0 degree)
0.0 to 359.9
It becomes the standard whether the
antenna actually points the direction of the
satellite.
ADE (status)
EL
Displays the elevation angle of antenna
(Displays the elevation which actually
the antenna points, when we assumed
horizontal direction as 0 degree, and
zenith as 90 degrees.)
-25.0 to 120.0
Cross EL
Cross elevation angle of antenna
(Displays the cross elevation angle
which actually the antenna points,
when we assumed front direction as 0
degree, horizontal direction as ±30.
-30.0 to 30.0
