10-3
RSSI-1:250
Displays the tracking-signal value for
radio wave tracking (direction face)
Displays 127 to 128 when tracking is normal
and the antenna is pointing the satellite
completely.
When the displayed data differs from above
one, antenna may not tracking satellite.
And in the case including RSSI-2 is lower
than normal value, improper radio wave
might caught although RSSI-1 displays
normal value.
These matters do not occur when GYRO is
used.
ADE (status)
RSSI-2:250
Displays the value of signal for step
track
0 to 250
Displays strength of received radio wave
from satellite. The values around 200 are
displayed in normal status. Lower value
will be displayed when satellite tracking
could not executed or blocking is occurred.
ADE Search
Displays the satellite search status of
ADE
0 to 6
(Detail is to be
determined)
GPS Status
Displays the reception status of GPS
unit.
3D FIX
Normally, the status is turned to 2D/3D Fix,
after power switch is ON. Communication
cannot start when GPS is not received.
It may take receiving time longer, when the
GPS hard to captures the satellite.
(Alarm bit display)
->refer to Alarm 1)
Alarm bit display of ADE
A:0001000000
0
Detail is shown in below table
