10-9
Status 1) (ADE Status bit display)
ADE Explanation of status Displayed value Criterion or explanation of situation
1
PLL LOCK
DET
Displays that PLL function of ADE operates
normally.
0;Unlock
1;Lock
Basically Lock is displayed.
Displaying Unlock indicates that tracking
malfunction is occurred.
It is no problem, when GYRO is used.
2
RATE
SENSOR
Displays rate sensor control ON/OFF command
that received from CCU.
0;Control OFF
1;Control ON
Basically ON is displayed
3 SERVO
Displays servo ON/OFF command that received
from CCU.
0;ON
1;OFF
Basically ON is displayed
4 STEPTRACK
Displays step track ON/OFF command that
received from CCU.
0;ON
1;OFF
Basically ON is displayed
5 Usests Input method of position information
0;Internal
1;Manual
To Next Page
