10-10
Status 2) (BDE Status bit display)
BDE Explanation of status Displayed value Criterion or explanation of situation
1 Backup
Displays backup application of IB (Interface
Board) is activated or not.
0；Not activated
1;Activated
2 Tracking type Displays which tracking system is used
0; Signal Tracking
1;GYRO use
3 GYRO type Displays which type of GYRO is used
0;NMEA
1;Sync/Step
4
Heading
request
Displays if Heading is requested from NSK
0;OFF
1;ON
5 Type Displays which type is used, Sync or Step
0;Sync
1;Step
6
7
RATIO Displays setting of NSK
00;360X, 01;90X,
10;180X, 11;36X
8
GYRO
direction
Direction of GYRO rotation
0; NORM
1; REV
9
10
GYRO output
timing
Serial output timing simulator
00;50ms, 10:100ms,
01;1s, 11:RESERVE
11 GYRO test Test status without GYRO signal
0; NORM
1; TEST
12 GYRO error Error detection time
0;0.2s,
1;5s
