Immergas MYTHOS HP - Page 22

22
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
1
2
13
Key (Fig. 13):
1 - Vertical terminal kit for direct exhaust
2 - Intake cover kit
14
15
e cover kit includes (Fig. 15):
No.1 e rmo for med c over
No.1 Gasket clamping plate
No .1 G a s ke t
No.1 Gasket tightening clip
e terminal kit includes (Fig. 15):
No .1 G a s ke t
No.1 Exhaust ange Ø 80
No.1 90° bend Ø 80
No.1 Exhaust pipe Ø 80
No.1 Wall sealing plate
