INSTALLERUSERMAINTENANCE TECHNICIAN
1.4 INSTALLATION INSIDE A
RECESSED FRAME OPTIONAL.
e boiler is designed for installation inside the
Immergas recessed frame (supplied as optional).
e necessary parts for this type of installation
(brackets) must also be purchased separately as
optional kit.
To install proceed as follows:
- Install the bracket (2) inside the recessed frame
xing it with the screws (3) in the pre-drilled
holes (Fig. 3).
- Hang the boiler (4) to the bracket (2) (Fig. 4).
- Block the boiler (4) by mounting the brackets
(5) and xing them with their screws (6) (Fig.
5).
e brackets (5) used to centre the boiler on
the frame and hold it in place stop against the
frame (1) so do not require xing to the frame
itself.
