4.3 TECHNICAL DATA.
- e data relating to domestic hot water performance refer to
a dynamic inlet pressure of 2 bar and an inlet temperature of
15°C; the values are measured immediately at the boiler outlet,
considering that to obtain the data declared, mixing with cold
water is required.
- * Eciencies refer to the net caloric value.
- e weighted NO
x
value refer to the net caloric value.
Victrix Tera 28 1 Victrix Tera 32 1 Victrix Tera 38 1
Domestic hot water nominal heat input kW (kcal/h) 28.8 (24773) 32.6 (28047) 39,0 (33567)
Central heating nominal heat input kW (kcal/h) 24.6 (21194) 28.6 (24588) 32,7 (28139)
Minimum heat input kW (kcal/h) 4.5 (3862) 5.1 (4413) 6,3 (5436)
Domestic hot water nominal heat output (useful) kW (kcal/h) 28.3 (24295) 32.0 (27520) 37,9 (32594)
Central heating nominal heat output (useful) kW (kcal/h) 24.1 (20717) 28.0 (24080) 32,0 (27520)
Minimum heat output (useful) kW (kcal/h) 4.3 (3689) 4.9 (4214) 6,1 (5246)
*Eective thermal eciency 80/60 Nom./Min. % 97.8 / 95.5 97.9 / 95.5 97,8 / 96,5
*Eective thermal eciency 50/30 Nom./Min. % 106.1 / 106.1 106.0 / 108.2 105,3 / 104,3
*Eective thermal eciency 40/30 Nom./Min. % 108.2 / 108.3 107.9 / 108.2 107,1 / 107,4
Casing losses with burner On/O (80-60°C) % 0.34 / 0.20 0.30 / 0.30 0,24 / 0,40
Chimney losses with burner On/O (80-60°C) % 0.02 / 1.70 0.02 / 2.20 0,01 / 2,50
Central heating circuit max. operating pressure bar 3 3 3
Maximum heating temperature °C 90 90 90
Adjustable central heating temperature (max operating eld) °C 20 - 85 20 - 85 20 - 85
System expansion vessel total volume l 5.8 6.4 7,1
Expansion vessel pre-charged pressure bar 1.0 1.0 1,0
Appliance water content l 2.2 2.41 3,8
Head available with 1000 l/h ow rate kPa (m H
2
O) 26.4 (2.7) 30.1 (3.1) 30,7 (3,1)
Hot water production useful heat output kW (kcal/h) 28.3 (24295) 32.0 (27520) 37,9 (32594)
Domestic hot water adjustable temperature °C 30 - 60 30 - 60 30 - 60
Domestic hot water circuit min. pressure (dynamic) bar 0.3 0.3 0,3
Domestic hot water circuit max. operating pressure bar 10 10 10
Flow rate capacity in continuous duty (∆T 30°C) l/min 14.1 16.5 18,6
Weight of full boiler kg 35.8 37.91 40,50
Weight of empty boiler kg 33.6 35.50 36,70
Electrical connection V/Hz 230 / 50 230 / 50 230 / 50
Nominal power absorption A 0.6 0.76 0,95
Installed electric power W 80 105 120
Pump absorbed power W 41 51 54
EEI value - ≤ 0.20 - Part. 3 ≤ 0.20 - Part. 3 ≤ 0,20 - Part. 3
Equipment electrical system protection - IPX5D IPX5D IPX5D
Max temperature of combustion products °C 75 75 75
Max. ue overheating temperature °C 120 120 120
NO
X
class - 6 6 6
Weighted NO
X
mg/kWh 35.0 30.0 39,0
Weighted CO mg/kWh 20.0 15.0 68,0
Type of appliance
C13 / C13x / C33 / C33x / C43 / C43x / C53 / C63 / C83
/ C83x / C93 / C93x / B23 / B33 / B53p
(**)
Victrix Tera 38 1
(**) Type of appliance
C13 / C13x / C33 / C33x / C43 / C43x / C53 / C53x / C63 / C63x / C83 / C83x
/ C93 / C93x / B23p / B33 / B53p
Category II 2H3P
