Immergas Zeus Superior - Combustion Parameters

40
STZSkW ed 12/07 ZEUS Superior kW
Technical DocumentationTechnical Documentation
Combustion parameters.
G20 G30 G31
Zeus Superior 24 kW
Gas nozzle diameter mm 1,35 0,79 0,79
Supply pressure mbar (mm H
2
O) 20 (204) 29 (296) 37 (377)
Flue ow rate at nominal heat output kg/h 50 49 51
Flue ow rate at minimum heat output kg/h 50 48 49
CO
2
at Q. Nom./Min. % 7,50 / 2,90 8,70 / 3,50 8,30 / 3,40
CO at 0% of O
2
at Q. Nom./Min. ppm 73 / 93 88 / 116 62 / 113
NO
X
at 0% of O
2
at Q. Nom./Min. ppm 138 / 75 186 / 83 181 / 87
Flue temperature at nominal heat output °C 115 118 114
Flue temperature at minimum heat output °C 98 102 100
Zeus Superior 28 kW
Gas nozzle diameter mm 1,35 0,79 0,79
Supply pressure mbar (mm H
2
O) 20 (204) 29 (296) 37 (377)
Flue ow rate at nominal heat output kg/h 58 55 57
Flue ow rate at minimum heat output kg/h 61 59 60
CO
2
at Q. Nom./Min. % 7,50 / 2,94 9,10 / 3,55 8,70 / 3,46
CO at 0% of O
2
at Q. Nom./Min. ppm 97 / 104 179 / 103 90 / 99
NO
X
at 0% of O
2
at Q. Nom./Min. ppm 123 / 77 184 / 89 168 / 88
Flue temperature at nominal heat output °C 108 115 111
Flue temperature at minimum heat output °C 79 82 81
Zeus Superior 32 kW
Gas nozzle diameter mm 1,35 0,79 0,79
Supply pressure mbar (mm H
2
O) 20 (204) 29 (296) 37 (377)
Flue ow rate at nominal heat output kg/h 66 66 68
Flue ow rate at minimum heat output kg/h 66 66 69
CO
2
at Q. Nom./Min. % 7,40 / 2,90 8,50 / 3,40 8,20 / 3,20
CO at 0% of O
2
at Q. Nom./Min. ppm 58 / 89 50 / 25 30 / 20
NO
X
at 0% of O
2
at Q. Nom./Min. ppm 119 / 65 153 / 84 167 / 137
Flue temperature at nominal heat output °C 119 121 118
Flue temperature at minimum heat output °C 95 96 92
