STZSkW ed 12/07 ZEUS Superior kW
Technical Documentation
Technical Documentation
ZEUS Superior 24 kW variable heat output.
ZEUS Superior 28 kWvariable heat output.
METHANE (G20) BUTANE (G30) PROPANE (G31)
HEAT
OUTPUT
HEAT
OUTPUT
BURNER GAS
FLOW RATE
BURNER
NOZZLES PRESSURE
BURNER GAS
FLOW RATE
BURNER
NOZZLES PRESSURE
BURNER GAS
FLOW RATE
BURNER
NOZZLES PRESSURE
(kW) (kcal/h)
(m
3
/h)
(mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O)
24.0 20640 2.71 12.02 122.6 2.02 28.86 294.4 1.99 36.88 376.2
21.5 18500 2.44 9.85 100.4 1.82 23.34 238.0 1.79 29.99 305.9
19.8 17000 2.25 8.45 86.2 1.68 19.87 202.7 1.65 25.64 261.5
19.2 16500 2.19 8.01 81.8 1.63 18.79 191.6 1.61 24.27 247.6
18.6 16000 2.13 7.59 77.4 1.59 17.74 181.0 1.56 22.95 234.1
18.0 15500 2.07 7.17 73.1 1.54 16.73 170.6 1.52 21.66 221.0
17.4 15000 2.01 6.76 69.0 1.49 15.75 160.6 1.47 20.42 208.3
16.9 14500 1.94 6.37 65.0 1.45 14.80 151.0 1.43 19.21 196.0
16.3 14000 1.88 5.98 61.0 1.40 13.89 141.6 1.38 18.04 184.0
15.7 13500 1.82 5.61 57.2 1.36 13.01 132.7 1.34 16.91 172.5
15.1 13000 1.76 5.25 53.5 1.31 12.16 124.0 1.29 15.82 161.4
14.5 12500 1.70 4.89 49.9 1.26 11.34 115.7 1.24 14.77 150.6
14.0 12000 1.63 4.55 46.4 1.22 10.56 107.7 1.20 13.75 140.2
13.4 11500 1.57 4.22 43.0 1.17 9.81 100.1 1.15 12.77 130.2
11.0 9500 1.32 3.00 30.6 0.98 7.13 72.8 0.97 9.22 94.1
9.3 8000 1.12 2.18 22.3 0.84 5.47 55.8 0.82 6.96 71.0
METHANE (G20) BUTANE (G30) PROPANE (G31)
HEAT
OUTPUT
HEAT
OUTPUT
BURNER GAS
FLOW RATE
BURNER
NOZZLES PRESSURE
BURNER GAS
FLOW RATE
BURNER
NOZZLES PRESSURE
BURNER GAS
FLOW RATE
BURNER
NOZZLES PRESSURE
(kW) (kcal/h)
(m
3
/h)
(mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O)
28.0 24080 3.16 11.41 116.4 2.35 28.79 293.7 2.32 36.66 373.9
25.0 21500 2.83 9.34 95.3 2.11 23.27 237.4 2.07 29.83 304.3
22.1 19000 2.51 7.53 76.8 1.87 18.50 188.7 1.84 23.88 243.6
21.5 18500 2.45 7.18 73.3 1.83 17.61 179.6 1.80 22.76 232,2
20.9 18000 2.39 6.84 69.8 1.78 16.74 170.8 1.75 21.67 221.0
20.3 17500 2.33 6.51 66.4 1.73 15.89 162.1 1.71 20.60 210.1
19.8 17000 2.26 6.18 63.1 1.69 15.06 153.6 1.66 19.55 199.4
19.2 16500 2.20 5.86 59.8 1.64 14.25 145.3 1.62 18.52 188.9
18.6 16000 2.14 5.55 56.6 1.59 13.46 137.2 1.57 17.52 178.7
18,0 15500 2.08 5.24 53.4 1.55 12.68 129.3 1.52 16.53 168.6
17.4 15000 2.01 4.93 50.3 1.50 11.92 121.6 1.48 15.57 158.8
16.9 14500 1.95 4.63 47.3 1.45 11.19 114.1 1.43 14.62 149.1
16.3 14000 1.89 4.34 44.3 1.41 10.47 106.7 1.39 13.70 139.7
15.7 13500 1.83 4.05 41.3 1.36 9.76 99.6 1.34 12.79 130.5
13.4 11500 1.58 2.95 30.1 1.17 7.13 72.7 1.16 9.37 95.6
11.8 10148 1.40 2.24 22.9 1.05 5.50 56.1 1.03 7.23 73.8
