42
STZSkW ed 12/07 ZEUS Superior kW
Technical DocumentationTechnical Documentation
ZEUS Superior 32 kW variable heat output.
METHANE (G20) BUTANE (G30) PROPANE (G31)
HEAT
OUTPUT
HEAT
OUTPUT
BURNER GAS
FLOW RATE
BURNER
NOZZLES PRESSURE
BURNER GAS
FLOW RATE
BURNER
NOZZLES PRESSURE
BURNER GAS
FLOW RATE
BURNER
NOZZLES PRESSURE
(kW) (kcal/h)
(m
3
/h)
(mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O) (kg/h) (mbar) (mm H
2
O)
31.7 27250 3.56 10.87 110.9 2.65 26.84 273.8 2.61 33.7 344.4
30.2 26000 3.40 9.95 101.5 2.53 24.62 251.2 2.50 31.98 326.2
29.1 25000 3.28 9.25 94.4 2.44 22.92 233.8 2.40 30.52 311.3
27.9 24000 3.15 8.58 87.6 2.35 21.29 217.2 2.31 29.05 296.3
26.7 23000 3.03 7.94 81.0 2.26 19.72 201.2 2.22 27.55 281.0
25.6 22000 2.91 7.33 74.8 2.17 18.22 185.8 2.13 26.03 265.6
24.4 21000 2.78 6.74 68.8 2.07 16.78 171.1 2.04 24.49 249.8
23.3 20000 2.66 6.18 63.0 1.98 15.39 157.0 1.95 22.93 233.8
22.1 19000 2.54 5.65 57.6 1.89 14.07 143.5 1.86 21.33 217.6
20.9 18000 2.41 5.14 52.4 1.80 12.80 130.5 1.77 19.71 201.1
19.8 17000 2.29 4.65 47.5 1.71 11.58 118.2 1.68 18.06 184.2
18.6 16000 2.16 4.19 42.8 1.61 10.43 106.4 1.59 16.38 167.1
17.4 15000 2.04 3.76 38.3 1.52 9.33 95.2 1.50 14.66 149.6
16.3 14000 1.91 3.35 34.2 1.43 8.29 84.5 1.41 12.91 131.7
14.0 12000 1.66 2.61 26.6 1.24 6.36 64.9 1.22 9.30 94.8
12.5 10750 1.50 2.19 22.4 1.12 5.28 53.8 1.10 6.95 70.9
