iDrive2 inverters Function Parameters
38
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P05.17
S2
terminal
switching off
delay time
0.000s
○
P05.18
S3 terminal
switching on
delay time
0.000s
○
P05.19
S3
terminal
switching off
delay time
0.000s
○
P05.20
S4 terminal
switching on
delay time
0.000s
○
P05.21
S4
terminal
switching off
delay time
0.000s
○
P05.22
S5 terminal
switching on
delay time
0.000s
○
P05.23
S5 terminal
switching off
delay time
0.000s
○
P05.32
Lower limit of
AI1
The function code defines the relationship between the
analog input voltage and its corresponding set value. If
the analog input voltage beyond the set minimum or
maximum input value, the inverter will count at the
minimum or maximum one.
When the analog input is the current input, the
corresponding voltage of 0~20mA is 0~10V.
In different cases, the corresponding rated value of
100.0% is different. See the application for detailed
information.
The figure below illustrates different applications:
0.00V
○
P05.33
Correspondi
ng setting of
the lower
limit of AI1
0.0%
○
P05.34
Upper limit of
AI1
10.00V
○
P05.35
Correspondi
ng setting of
the upper
100.0%
○
