IMO iDrive2 XKL - Page 58

iDrive2 inverters Function Parameters
58
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P10.28
Multi-stage
speed 13
Select at most 16 stages speed via the combination
code of S1, S2, S3, and S4.
The start-up and stopping of multi-stage running is
determined by function code P00.06, the relationship
between S1,S2,S3,S4 terminals and multi-stage speed
is as following:
S1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
S2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
S3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
S4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
stage
0
1
2
3
4
5
6
7
S1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
S2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
S3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
S4
ON
ON
ON
ON
ON
ON
ON
ON
stage
8
9
10
11
12
13
14
15
Setting range of P10.(2n,1<n<17): -100.0~100.0%
0.0%
○
P10.30
Multi-stage
speed 14
0.0%
○
P10.32
Multi-stage
speed 15
0.0%
○
P11 Group Protective parameters
P11.01
Sudden
power loss
frequency
decreasing
function
selection
0: Enabled
1: Disabled
0
○
P11.02
Frequency
decreasing
ratio of
sudden
power loss
Setting range: 0.00Hz/s~P00.03 (the Max. frequency)
After the power loss of the grid, the bus voltage drops to
the sudden frequency-decreasing point, the inverter
begin to decrease the running frequency at P11.02, to
make the inverter generate power again. The returning
power can maintain the bus voltage to ensure a rated
running of the inverter until the recovery of power.
Voltage rating
230V
400V
Frequency-decreasing point
of sudden power loss
260V
460V
Note:
1. Adjust the parameter properly to avoid the stopping
caused by inverter protection during the switching of the
grid.
10.00Hz/
s
○
