Step of program ‘rinsing’
Required temperature of water between 20 and 70°C
Running time between 2 and 20 minutes after heating water of
required temperature.
EC-limit between 10 and 200µS or ‘without’
(Measurement for conductivity for this step of rinsing)
Indication: If a conductivity limit is indicated, so it will be assinged
the same ec-limit to all following rinsing processes.
If a preceding rinsing process exists with an ec-limit , then this can’t
be changed in the current rinsing process.
Step of program ‘drying’
Required air-temperature at the air outlet of blower
range between 50 and 100°C.
Required drying level of the warm air within the range of stage 1 to 8.
At stage 8 you get a drying with the lowest rest of humidity.
Time within the range of 0 to 600 minutes, in which after reaching
dry level of air drying continues, for example for drawing parts such
as socket contacts drying completely.
Indication: After step of ‘drying’ no further step program possible.
Rules of program-construction:
- No further step of program after ‘drying’ possible.
- Between two program steps no empty (deleted) program step may be.
- After rinsing with EC-limit no cleaning step can follow. In the reversal conclusion also EC-limit can
not be assigned to a rinsing step before a cleaning step.
- If an EC-limit is assigned to a rinsing step, all following rinsing steps have the same EC-limit,
(the cleaning is adequate).
- If an EC-limit of a rinsing step is abode, so each further rinsing step will be overleaped, because
enough cleaning is reached.
- Maximal 10 program steps are possible.
step no.: 02
type: rinsing
temperature: 30°C
duration: 2min
ec-limit: 40µS
programme no. 2
step no.: 03
type: drying
temperature: 90°C
drying grade: 5
run after: 10min
programme no. 2
