2.Schedule of connection Öko 2000
NE water deionizer with conductivity measurement
Back side
ÖKO2000
Filter candle
Filter housing
Waste water
Hose end in no
case lower than
the level
alternatively
detergent
container
Observe local wastewater discharge
regulations
Network
Wastewater hose
Mount the filter cartridge at the height
of the upper edge of the machine.
Air filter
Dosing unit
Connections
Water inlet
live -
with
230V 50Hz when filling
Water desalination unit
Fresh water
inlet
Solenoid valve directly on
permanently installed water
connection / Observe
installation direction
T-piece brass
E.C. Measuring cell LM-LED
1804.0000.39
