IMO GmbH Gässlesweg 6 D-75334 Straubenhardt Tel.: 070 82 491 80 Fax: 604 36 www.imo-ag.com info@imo-ag.com
6
GmbH
End of waste water hose
min. 300 mm
End of waste water hose
Alternative
min. 300 mm
2.1 Schedule of connection of effluent hose
For to avoid an uncontrolled drain of water out of the cleaning system, the open, and thereby
aerated end of waste water hose has to be mounted after the waste water filter at least
30 cm above the installation surface of the ÖKO 2000.
If the hose ends lower, it may be possible that because of the vacuum lifting effect, the
water drains out of the machine.
