Tolerance Displays - cont:
16
CHANNEL Y X(?)
Next/No
Next/No
--The number in parenthesis is the
variance IMPAX is detecting in the
forming process, also on a scale of 1 to
9. The tolerance can be set lower or
higher than the variance. When there is
a (?) in the variance, it means that
IMPAX is still learning.
--If the tolerance is set for automatic,
the “*” will appear after the channel
number and it may be accompanied by a
(number) which indicated the
equivalent tolerance level or a (?)
Which means no tolerance has been
computed yet.
--An “N” means that no tolerance has
been set; the setup is not complete and
the job may not be started.
Press Next/No. The display will show
the next channel, for instance,
“STATION 2 8(6)”, which would mean
that channel 2 is set for tolerance level 8
but should be set lower. IMPAX is
suggesting that it would run on a
tolerance of 6.
Press Next/No again, and the next
channel will be displayed. This may be
repeated until all the desired channels
have been displayed.
Press Back at any time to return to the
previous display.
If you wish to change a tolerance
setting you must insert the
Supervisor’s Key and proceed as
instructed in Chapter 5, Tolerance
Setting Guide.
Note: Roller tolerances are set the same
way as header tolerances, except that
“CHANNEL 1” will be replaced by
“ROLL” or whatever name is assigned.
Press Display Will Show
X is the tolerance setting for channel Y
X can be from 0 to 9, or *.
until all channels have been displayed
