Chapter 8 - Diagnostics
DEFINITION OF DIAGNOSTIC FEATURES FOR ALL IMPAX
SYSTEMS
Getting Into Diagnostics:
Turn the SUPERVISOR'S KEY to the on or horizontal position. (Note if the IMPAX is
currently in a force or tolerance screen the Clear key will have to be pressed to get back to a
quantity screen.)
Press Function (#). The display will show “SELECT FUNCTION”.
Press the number 4 key. (Function 4 selects the diagnostics mode.) The display will show
“ACCESS _”.
Enter the access code by pressing the numbers 5, 6, 8, 6, then press Enter/Yes, the display will
show “REDEFINE?”. This is asking if you wish to redefine the access code from 5686 to a four
digit number of your choice.
If you answer no by pressing Next/No. The display will show “DIAGNOSTICS”. If you wish to
redefine the access code press Enter/Yes at the “REDEFINE?” prompt. The IMPAX will ask
you for a NEW access code. Press any four digit number combination then press Enter/Yes. The
display now shows “ACCESS _”. Press the same four digit code you just entered, then press
Enter/Yes. The display will now show “DIAGNOSTICS”. You can exit the diagnostics mode at
any time by pressing Clear.
Diagnostic Functions:
Versions' 47.xx, 50.xx, and 57.xx:
Press the number 2 key the IMPAX will display the old communications parameters.
Press the ENTER/YES key to step through the various settings. These settings will have no
effect on the IMPAX operation since they are no longer used.
Versions' 48.xx and 58.xx:
Press the number 9 key. If the display shows _ _ _ _ _ _ _ _ _ _ _ _ _ _ _, there is nothing being
transmitted or received by the IMPAX unit via the IMPAXNET. If the display has characters on
