Chapter 9 - Specifications and Drawings
SPECIFICATIONS
Controller type: Microprocessor-controlled monitoring and control system for forming
machines.
Measuring System: Force and pressure sensing by piezoelectric transducers; typical size 1-1/8
inch diameter by 1/8 inch thick, or less. Output range: .4 to 200 volts.
Interpreted by 8-bit analog-to-digital converter.
Timing System: Parts counting and measurement timing by non-contact metal detecting
switches on cams or other machine parts. 10-volt output pulse.
Operator Controls
and displays: At machine: “RESET” button and red status light.
At console: Alphanumeric display for measurement and messages, push-
button controls, and Supervisor Keylock to protect settings.
Machine Control: Four relays, operating independently. Immediate, timed, or cycled delay.
Each rated 8 amps, 250 volts AC maximum. May be used to stop machine,
feed, output diverter, or other accessories.
Power
Requirements: 115 volts at 1 amp or 230 volts at ½ amp, 50/60 Hz AC. IMPAX is protected
against surges and motor interference.
Dimensions: Satellite Box: 8" H x 6" W x 4" D
Control Console: 11-3/4" H x 10-3/4" W x 9" D
Satellite Cable: multi conductor, oil resistant covering, 10 foot length
Console weight: Approx. 30 lbs
Distance from IMPAX to machine: Recommended maximum of 20 feet
Environmental
Protection: Satellite Box and fittings are sealed to NEMA 13. Resistant to oil, heat, and
vibration.
Control Console: Keyboard and case are resistant to oil, smooth and easy to clean. Withstand
extremes of temperature and humidity. Resistant to static electrical
discharge.
Battery: Ni Cad - rated for 6-8 year life.
