NanoPhotometer
®
P-Class User Manual
Version 2.1 Page 50 / 70
Calibration (Manual entry)
Results screen
Menu (select using key pad numbers)
Calibration (Manual entry)
Step 24 Shows previously entered calibration values and allows
values to be entered via the keypad.
Step 25 The highlighted box can be edited in order to enter an
absorbance value corresponding to a given concentration
value using the keypad numbers. Range 0.001 to 9,999.
Use C to backspace and clear the last digit entered and
the up and down arrows to move between boxes.
Step 26 Press OK to accept the calibration and go to the
Results screen (see below) OR press Back to return to
the Standards screen.
Results screen
Step 27 Insert the reference sample and press Blank key. This will
be used for all subsequent samples until changed.
Step 28 Insert the sample and press Sample . The
concentration of the sample is taken and displayed.
Step 29 Repeat for all samples.
Step 30 Press Menu/Options to display available options which
are described below.
Step 31 Press Escape and confirm with Yes to return to the
Functions folder. Query needs confirmation to avoid
unintended escaping the application.
Menu (select using key pad numbers)
1) Return to parameters screen.
2) Transfer the results via selected Output Options / Printer
settings.
7) Sample number – add a prefix to the sample number and
reset the incrementing number to the desired value.
8) Save method – use the left and right arrows to select a folder
to store in (User Methods 1-9), press the down arrow and enter
name.
9) Open Output Options/Printer settings, possibility to change the
Output / Printer settings within the method as described in 7.3
Output Options / Printer
Exit Menu/Options by pressing Escape , or wait.
