IMS MicroLYNX - Expanding the Isolated Digital I;O

35
Expanding the Isolated Digital I/O
The Isolated Digital I/O can be expanded to 24 lines. Expansion to this level
would require the use of all three slots. The I/O groups are slot dependent. The
slots will yield the following groups as numbered:
Slot 1 ......................................................... Group 30
Slot 2 ......................................................... Group 40
Slot 3 ......................................................... Group 50
Installing The Isolated Digital I/O Module
To install the Isolated Digital I/O Expansion Module in your MicroLYNX,
perform the following in accordance with Figure 9.1.
1] Remove screws (A).
2] Remove panel from slot to be used.
3] Insert Isolated Digital I/O Module into Slot 1 (C), Slot 2 (D)
or Slot 3 (E).
4] Press firmly until expansion board is securely seated and
locked into place by retaining clips (F).
5] Reassemble MicroLYNX case in accordance with Figure 9.1.
6] Affix labels as shown. Use a highlighter or marker pen to
highlight slot(s) used.
#niP
noitpOrotcennoC
xineohPnoitisoP8 redaeHniP01
1tolS 2tolS 3tolS 1tolS 2tolS 3tolS
1
V
pullup
V
pullup
V
pullup
13OI14OI15OI
2
13OI 14OI 15OI 23OI 24OI 25OI
3
23OI24OI25OIV
pullup
V
pullup
V
pullup
4
33OI 34OI 35OI 33OI 34OI 35OI
5
43OI44OI45OI.C.N.C.N.C.N
6
53OI 54OI 55OI 43OI 44OI 45OI
7
63OI64OI65OI.C.N.C.N.C.N
8
DNGO/I DNGO/I DNGO/I 53OI 54OI 55OI
9
DNGO/IDNGO/IDNGO/I
01
63OI 64OI 65OI
Table 9.2: Isolated Digital I/O Group and Line Locations by Connector Option and Slot
