IMS MicroLYNX - Tools and Equipment Required; Recommended Stepping Motors

11
Connecting A Motor
Tools and Equipment Required
The following is required to connect a motor to your MicroLYNX
System:
 A stepping motor.
 Motor cabling (if the motor is not so equipped.).
 A small standard screwdriver.
A Stepping Motor
IMS recommends the following 1.8° Hybrid Stepping Motors for
the MicroLYNX System. All IMS motors are CE marked. For
more detailed information on these motors, please see the IMS
motor catalog or the IMS website at www.imshome.com.
17 Frame (MicroLYNX - 4)
Single Shaft Double Shaft
M2-1713-S ................................................................................ M2-1713-D
M2-1715-S ................................................................................ M2-1715-D
M2-1719-S ................................................................................ M2-1719-D
23 Frame (MicroLYNX - 4/-7)
Single Shaft Double Shaft
M2-2215-S ................................................................................ M2-2215-D
M2-2220-S ................................................................................ M2-2220-D
M2-2232-S ................................................................................ M2-2232-D
M2-2240-S ................................................................................ M2-2240-D
34 Frame (MicroLYNX - 7)
Single Shaft Double Shaft
M2-3424-S ................................................................................ M2-3424-D
M2-3437-S ................................................................................ M2-3437-D
M2-3450-S ................................................................................ M2-3450-D
Enhanced (Higher Torque) Stepping Motors
IMS also carries a new series of 23 frame enhanced stepping motors that are
recommended for use with the MicroLYNX System.
Single Shaft Double Shaft
MH-2218-S ............................................................................. MH-2218-D
MH-2222-S ............................................................................. MH-2222-D
MH-2231-S ............................................................................. MH-2231-D
For instructions on sizing a
motor for your application,
see Part 2, Section 5 of
the Product Manual
pdf on the CD!
3
