IMS MicroLYNX - Read and Feed

70
Read And Feed
This program reads the state of two inputs to determine a move distance, and
makes the move.
Steppin
g
Motor
MicroLYNX or LYNX Control
Module + Step Motor Driver
BIT 0
BIT 1
START
IO 22
IO 21
IO 23
IG
Figure 12.3: Read And Feed Application
START
Read Inputs
to determine
move distance
Move selected
distance
END
Figure 12.4: Read And Feed Application Flowchart
