IMS MicroLYNX - Registration

75
Registration
This program feeds a web at a constant velocity and executes a registration move
of a user-defined distance after a registration sensor becomes active. After the
completion of the move, an output is switched ON/OFF. Operation starts when
the START button is pressed and ends when either the STOP button is pressed,
the batch is complete, or material runs out.
PARTS MADE:11
Steppin
g
Motor
Material
Sensor
Registration
Mark Sensor
Nip Rollers
C utter
Human
Machine
Interface
(HMI)
START
STO P
MicroLYNX
with Differential I/O
Expansion Module
-OR-
LYN X Control
Module with Differential
I/O Module and Step
Motor Driver
Figure 12.7: Registration Application
