IMT 3203i Parts & Specifications

Specications 18 Crane Reference
3203i - Manual # 99904380
99904394 PARTS LIST
ITEM NO. PART NO. DESCRIPTION KIT NO. QTY.
1. 51721572
KIT-ELECTRICAL CRANE BODY INSTALLATION
(FOR DUAL UNDERHOOD BATTERY)
1
2. 91721647 KIT-HRDW 3203I/4004I ELEC CRANE BODY INSTL 1
3. 91721751 KIT-HRDW 5005I ELEC CRANE BODY INSTL 1
4. 51725112 KIT-ELECTRIC CRANE BODY INSTALLATION 1
5. 51725572
KIT-ELECTRIC CRANE BODY INSTALLATION
(FOR SINGLE UNDERHOOD BATTERY)
1
6. 99904317 DWG-CRANE & WINCH ASM 3203I REF
7. 60251272 BRKT-SWITCH 300 AMP ELEC CRANE 1, 4, & 5 1
8. 70734331 SWITCH-300A KEYED BATTERY DISCONNECT 1, 4, & 5 1
9. 72042097 LEVEL INDICATOR LEVEL 1, 4, & 5 1
10. 77040209 TERM-RING NI .38 STUD 1 WIRE 1 & 4 1
11. 77040529 TERM-RING NI .31 STUD 1-2 WIRE 1 & 4 3
11. 77040529 TERM-RING NI .31 STUD 1-2 WIRE 5 9
12. 77441116 FUSEHOLDER-HIGH AMP2 BOLT WITH COVER 1 1
12. 77441116 FUSEHOLDER-HIGH AMP2 BOLT WITH COVER 5 2
13. 77441219 FUSE-AMG-225 AMP 1 & 4 1
13. 77441219 FUSE-AMG-225 AMP 5 2
14. 89044276 CABLE-#1 WELDING PRESTOL 1 & 5 35 FT
15. 89392333 TUBE-HEAT SHRINK AMP 603328-20 1, 4, & 5 .50 FT
16. 72060207 CAP SCR .75-10X 3.00 HH GR8 Z 2 4
17. 72601621 CAP SCR 1.00- 8X 3.00 HH GR8 Z 3 4
18. 72601862 NUT .75-10 HEX GR8 YZ NYLOCK 2 4
19. 72062375 NUT 1.00- 8 HEX GR8 YZ NYLOCK 3 4
20. 72063116 WASHER .75 N FLAT H ASTMF436Z 2 8
21. 72063066 WASHER 1.00 FLAT HI STR 3 8
22. 72060002 CAP SCR .25-20X .75 HH GR5 Z 2 & 3 4
23. 72060634 SCR-MACH #10-24X .50 RDH 2 & 3 4
24. 72062000 NUT .25-20 HEX 2 & 3 4
25. 72062106 NUT 10-24 HEX NYLOCK 2 & # 4
26. 72063001 WASHER .25 FLAT 2 & 3 8
27. 77441396 WIRE-2 GA GXL RED 4 35 FT
28. 77040009 TERM-RING NI .38 STUD 2 WIRE 4 1
29. 77041774 STUD-BULKHEAD PASS THRU 3/8” BLACK 1
REV. G CN1000
