VGC
TM
SEQUENTIAL VALVE GATE CONTROL
INSTRUCTION MANUAL
©INCOE® CORPORATION 2/2009
Pg.
www.incoe.com
TABLE OF CONTENTS
1
1 INTRODUCTION
1.1 Programming Pg. 2
1.2 Control Pg. 2
1.3 Signals Coming from the Injection Molding Machine Pg. 2
1.4 Connecting Signals Coming from the Press Pg. 2
1.5 Security Pg. 4
1.6 Connections for VGC Sequential Valve Gate Control Cabinet Pg. 5
1.7 Dimensions in. (mm) Pg. 5
1.8 Fuses and Circuit Breakers Pg. 5
1.9 Applicable Standards Pg. 5
1.10 Wiring Diagram of VGC Sequential Valve Gate Control Cabinet Pg. 6
1.11 Machine Interface Pg. 7
2 OPERATION
2.0 Starting Up Pg. 8
2.1 Calibration Pg. 8
2.2 Configuration of the System Pg. 9
2.2.1 Duration of the Closing Signal at the End of the Injection Cycle Pg. 9
2.2.2 Delay Before Position Control Pg. 9
2.2.3 Prolonging of Injection Signal Pg. 9-10
2.2.4 Selection of Unit for Screw Travel Pg. 10
1. Unit in % Pg. 10
2. Unit in mm Pg. 10
3. Unit in cm
3
Pg. 10
2.3 Manual Mode Pg. 11
2.4 Modify a Program Pg. 12
2.5 File Management Pg. 14
2.6 Management of Alarms: Pg. 15
Select and Validate the Function ALARM from the Main Page.
2.7 Main System Parameters Values Pg. 16
2.8 System Locking Pg. 16
2.9 Option Position Control of Pins Pg. 16
2.10 List of Main Spare Parts Pg. 18
3 TROUBLESHOOTING
3.1 Troubleshooting Pg. 19
4 WARRANTY
4.1 General Terms & Conditions of Sale Pg. 24
5 CONTACT
5.1 Global Service Contacts Pg. 26
5.2 Global Offices Pg. 27
