17 Page 17 - 8 Tank Sentinel Setup Programming Guide
Worksheet # 17-5 – Output Groups – Sensor Channels 33 to 40
Fill-in the work sheet below and compare assignments with other work-sheets to
uncover conflicts before programming output devices. (For TS-2001/508 only).
A maximum of
3 alarm Output
Groups ( OG )
can appear per
channel # N...
TSP-DDS &
TSP-DTS
sensors have
3 alarms:
water,
product &
sump full.
Alarm OGs are:
STD (standard)
PROD
(product)
WATER OG
SMP FL
(sump full)
DRY WL
(dry well)
HGH BR (high
brine level)
LOW BR (low
brine level)
VAPOR OG
Write-in all
alarm OG
for each
sensor
channel #.
OG = Output Group
- Out
p
ut Grou
p
Assi
g
nment WORKSHEET Out
p
ut Grou
p
choices -
Sensor #33
(TS-2001): NONE
A
B
C
Sensor #34
(TS-2001):
D
E
F
G
Sensor #35
(TS-2001):
H
I
J
K
Sensor #36
(TS-2001):
L
M
N
O
Sensor #37
(TS-2001):
P
Q
R
S
Sensor #38
(TS-2001):
T
U
V
W
Sensor #39
(TS-2001):
X
Y
Z
AA
Sensor #40
(TS-2001):
BB
CC
DD
EE
ex.:
HGH BR OG 401
P
Could activate the annunciator when a high brine level is detected … see
below also
FF
LOW BR OG 401
P
Could disable product dispensing when a low brine level is detected
…see above also
(
TSP-HIS shown
)
ALL
Output Devices: Modulated Annunciator, Solid Annunciator, Relay 1, Relay 2, I/O Output Module
Channel # 1 to # __ (record all OG Assignments in the vertical column)
