16 Page 16 - 2 Tank Sentinel Setup Programming Guide
TS-ROM Menu (C ONTINUED ... FROM PREVIOUS PAG E )
TS-ROM Channel 1 Output Group (alarm assignment)
CHANNEL 1
TS-ROM CHANNEL 1 Select / assign output group(s) to activate
OUT GRPS the TS-ROM Channel Relay 1 on alarm
TS-ROM OUTPUT GROUPS 1 GROUP
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – A
1 32
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z AA BB CC DD EE FF
Fill–in TS-ROM Channel Relay 1 Output – Group Assignments Below:
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z A A B B C C D D E E F F
TS-ROM Channel 2 Output Group (alarm assignment)
CHANNEL 2
TS-ROM CHANNEL 2 Select / assign output group(s) to activate
OUT GRPS the TS-ROM Channel Relay 2 on
TS-ROM OUTPUT GROUPS 2 GROUP
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – A
1 32
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z AA BB CC DD EE FF
Fill–in TS-ROM Channel Relay 2 Output – Group Assignments Below:
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z A A B B C C D D E E F F
TS-ROM Channel 3 Output Group (alarm assignment)
CHANNEL 3
TS-ROM CHANNEL 3 Select / assign output group(s) to activate
OUT GRPS the TS-ROM Channel Relay 3 on alarm
TS-ROM OUTPUT GROUPS 3 GROUP
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – A
1 32
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z AA BB CC DD EE FF
Fill–in TS-ROM Channel Relay 3 Output – Group Assignments Below:
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z A A B B C C D D E E F F
NOTE
☞
The 24
TH
group
(Group X) is shown
assigned
Y
Example Output Device — OUTPUT GROUP Assignment (shown filled-in)
ABCDEFGH I JKLMNOPQRSTUVWXYZA AB BC CD DE EF F
Y YYY Y
OUTPUT GROUP GROUP
Y – – Y Y Y – – – – – – – – – – – – – – – – – Y – – – – – – – – X
1 32
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z AA BB CC DD EE FF
Press: M1 to move the cursor left ï
M2 to move the cursor right ð M4 to backspace (delete) one character to the left ï
UP / DOWN ▲▼ to select (Y for yes assigned, or – (dash) for no not assigned)
ENTER to store the setup into the system memory
