Incon task sentinel TS-750 User Manual

Lines Setup Page 3 - 1 3
3 Lines SETUP PROGRAMMING
Lines Menu
H U
MENU × Press this key and follow the
7
highlighted sequence below
SELECT MENU OPTION
SETUP UPGRADE LANGUAGE DATALOG
M1 M2 M3 M4
SETUP MENU (MORE)
EXIT SYSTEM TANKS LINES
M1 M2 M3 M4
LINES
DATA
M1 M2 M3 M4
NOTE
☞
Only the NO. (of) LINES programmed under the
system menu are shown here ! This menu applies
to consoles that have a L in the part number (
LLDI
enabled – CHECK OPTIONS).
Disregard this menu when it’s not displayed.
The purpose of this menu is to allow renaming of
the line to help identify its location. The new line
name will appear on reports and at the local tank
gauge display.
Changing the Line Name is optional.
Use the ▲ UP or DOWN ▼ key to display LINE 5
through LINE 8.
Use a menu select keys to choose a line.
Remember:
• Use ▲ UP or DOWN ▼ key to display more
menus or selections (when MORE or
UP/DN is shown)
• Press CANCEL to cancel a data entry
• Use the ENTER key to accept data
Character input / editing:
• Press M4 to backspace (delete) one
character to the left ï
• Use M2 to move the cursor right ð
• Press M1 to move the cursor left ï
See the Table of Contents to find topics in
this manual. See the Preface for general
information about this manual. And see the
Installation, Operator’s, TroubleShooting
Guides, and Application Notes for other
reference material.
Contents:
Lines Menu
Line Data Menu
LINE DATA (MORE)
LINE 1 LINE 2 LINE 3
M1 M2 M3 M4
LINE DATA N (MORE)
NAME
M1 M2 M3 M4
LINE NAME N A...M
LINE 1 BACKSPACE
M1 M2 M3 M4
