Page 22 - 2 Tank Sentinel Setup Programming Guide
NOTE
☞
CVS Tanks Menu
After programming the maximum number of sensors from the SYSTEM menu, access
the CVS Tanks menu and program each sensor to associate it with a particular tank.
•
The default programming is 0 (no sensor is associated with a Tank)
•
SCALD or Standard Monthly tank leak testing is not disabled by CVS for tanks
•
A sensor can be associated with single or multiple (compartmental) CVS tank(s)
•
The maximum number of sensors is determined by No. Sens[ors]
(number of
sensors) specified-programmed in the SYSTEM menu
•
A sensor that is associated to a CVS tank must be physically present (wired to the
Tank Sentinel Console – at sensor channel number N).
See the console I.S.
Sensor PC Board to verify which channels are used/wired-to, and
TABLE 2 at the back of this manual...
•
A sensor cannot be associated to both a line and tank (sensors must be
associated to either a Tank or Line)
•
A SENSOR UNAVAILABLE
error message
is displayed if any of the above error
conditions
(italic)
are present
Press the MENU key and press:
SETUP Press the
M1
key under the word SETUP
Press the
M
key under the word CVS
Press the
M1
key under the word TANKS at the Compliance Via Sensors menu
CVS TANKS (MORE)
TANK 1 TANK 2 TANK 3 TANK 4
First display menu
TANK 5 TANK 6 TANK 7 TANK 8 Second display menu
Press the
Menu Select key
under the Tank N, or press the
DOWN Key if (MORE) is shown in the second display menu for
TANKS 5 to 8 (only on consoles that accept more than 4 tanks)
COMPLIANCE SENSOR CVS TANK N (N = Tank number)
0
1 - 32
Use keypad to input the sensor number that is associated
with this particular tank.
Press
ENTER
to accept this data.
A sensor may be enabled for more than one tank. The CVS feature is enabled
when a sensor is associated with a CVS tank or line under the CVS menu.
— Repeat for each TANK number —
— Press the CANCEL key to return to the previous menu —
To Next Page
